3
CF65/75/85 series Disassembly and assembly
PROP SHAFTS
4-7
8. Unscrew the flange with bearing and rubber
block (2) from the bracket.
9. Press the flange from underneath and press
the bearing out.
10. Press the bearing with one sealing ring (1)
out of the rubber block.
11. If necessary, remove the second sealing
ring (1).
Note:
In case of damage, always replace the
entire centre bearing.
W 3 06 022
W 3 06 023
1 2314 5
11
ᓻ 0111
