3
PROP SHAFTS
Disassembly and assembly CF65/75/85 series
4-8
Assembling the centre bearing
1. Press the sealing ring into the bush of the
rubber block until it aligns with the outside
of the bush.
2. Press the bearing along the other side into
the bush. Then the other sealing ring can be
pressed into the bush. Apply grease to the
sealing rings (1).
W 3 06 021
W 3 06 026
W 3 06 025
1
11
ᓻ 0111
