3
CF65/75/85 series Disassembly and assembly
PROP SHAFTS
4-9
3. Press the assembly onto the flange, the
larger space between bearing and sealing
ring facing the flange.
4. Install the centre bearing assembly in the
bracket and lock it with the lock plate.
5. Install the centre bearing onto the auxiliary
shaft. Make sure that the centre points are
aligned to ensure that later all forks are in
one line.
6. Attach the centre bearing to the chassis by
means of bolts, but do not tighten the bolts.
7. Tighten the central nut of the centre bearing
to the specified tightening torque. See
“Technical data”.
Then apply Loctite 243 to the attachment
bolts of the centre bearing to the chassis
and carry out final tightening to the specified
tightening torque. See “Technical data”.
W 3 06 024
W 3 06 029
W 3 06 018
11
ᓻ 0111
