DAF CF75 Series - Page 397

3
CF65/75/85 series Removal and installation
ZF INTARDER
4-15
12
11
10
9
8
7
5
6
4
3
2
1
13
V300077
6. Install the piston (9) on the selector shaft
and tighten the lock nut (6) to the specified
torque. See “Technical data”.
7. Install the cylinder (2) and tighten the
attachment bolts to the specified torque.
See “Technical data”.
8. Connect the air supply.
9. Install the intarder.
12
ᓻ 200337
