3
CF65/75/85 series General
PTO
2-21
2.19 OVERVIEW DRAWING, 2266 PTO, B VERSION
V300631
10
6
5
4
3
2
1
7
8
11
12
13
14
18
15
16
17
9
1. PTO cover
2. Gasket
3. Drive sprocket
4. Spacer ring
5. Piston
6. Spring
7. Shim
8. PTO housing
9. Gasket
10. PTO cover
11. Lock washer and nut
12. Output shaft
13. Drive flange
14. Locking plate
15. Shaft seal
16. Air connection
17. O-ring
18. Lock washer and bolt
13
ᓻ 200337
