3
PTO
General CF65/75/85 series
2-22
2.20 OVERVIEW DRAWING, 2266 PTO, C VERSION
V300632
12
9
10
6
5
4
3
2
1
7
8
13
16
14
15
11
1. PTO cover
2. Gasket
3. Drive sprocket
4. Spacer ring
5. Piston
6. Spring
7. Shim
8. PTO housing
9. Bolt
10. Output shaft
11. Gasket
12. Transport cover
13. Lock washer and nut
14. Air connection
15. O-ring
16. Lock washer and bolt
13
ᓻ 200337
