PTO
Removal and installation CF65/75/85 series
4-2
4.2 REMOVAL AND INSTALLATION, DAF ENGINE PTO FLYWHEEL HOUSING
Removing DAF engine PTO flywheel housing
1. Remove the gearbox.
2. Remove the clutch release assembly and
the flywheel.
3. Remove the PTO housing from the flywheel
housing.
4. Remove the attachment bolt from the upper
drive sprocket in the flywheel housing.
5. Suspend the engine in a hoist.
6. Suspend the clutch housing in a hoist.
7. Remove the engine bracket attachment
bolts.
8. Remove the bolts attaching the flywheel
housing to the engine block.
9. Remove the flywheel housing.
10. Remove the two drive sprockets from the
flywheel housing. Be aware of the mounting
position of the sprockets.
11. Remove the oil seal from the flywheel
housing.
Installing DAF engine PTO flywheel housing
1. Fit a new oil seal in the flywheel housing.
2. Fit the two drive sprockets into the flywheel
housing.
3. Install the flywheel housing and tighten the
upper drive sprocket attachment bolt to the
specified torque. See “Technical data”.
4. Fit the bolts attaching the flywheel housing
to the engine block and tighten them to the
specified torque. See “Technical data”.
13
ᓻ 200337
