3
PTO
Removal and installation CF65/75/85 series
4-4
4.4 REMOVAL AND INSTALLATION, NH/1 AND NL/1 PTO, C VERSION
Removing NH/1 and NL/1 PTO, C version
1. Drain as much gearbox oil as necessary
and collect it in a clean container.
2. Remove the electrical connector and air
pipe from the PTO.
3. Remove the drive flange, which is mounted
against the PTO flange.
4. Remove the attachment nuts connecting the
PTO to the gearbox and remove the PTO
including selector sleeve and gasket.
5. If necessary, remove the intermediate shaft.
Installing NH/1 and NL/1 PTO, C version
1. If necessary, install the intermediate shaft.
2. Install the gasket over the studs.
3. Install the PTO with selector sleeve onto the
gearbox.
4. Fit the attachment nuts onto the studs of the
gearbox and the PTO.
5. Connect the electrical connector and air
pipe to the PTO.
6. Install the drive flange against the
PTO flange.
7. Check the oil level in the gearbox.
13
ᓻ 200337
