3
PTO
Removal and installation CF65/75/85 series
4-10
4.9 REMOVAL AND INSTALLATION, NL/1 PTO ON N221/10 PTO
Removing NL/1 PTO on N221/10 PTO
1. Drain as much gearbox oil as necessary
and collect it in a clean container.
2. Remove the electrical connector and air
pipe from the PTO.
3. Remove the drive flange, which is mounted
against the PTO flange.
4. Remove the attachment bolts from the
NL/1 PTO on the N221/10 PTO.
5. Remove the PTO, gasket and intermediate
housing.
Installing NL/1 PTO on N221/10 PTO
1. Check and adjust the axial play before
attaching the NL/1 PTO to the
N221/10 PTO.
2. Fit a new gasket and the intermediate
housing.
3. Install the PTO.
4. Connect the electrical connector and air
pipe to the PTO.
5. Install the drive flange against the
PTO flange.
6. Check the oil level in the gearbox.
13
ᓻ 200337
