CF65/75/85 series Removal and installation
PTO
4-11
4.10 REMOVAL AND INSTALLATION, N AS/10 PTO
Removing N AS/10 PTO on gearbox
1. Drain as much gearbox oil as necessary
and collect it in a clean container.
2. Remove the electrical connector and air
pipe from the PTO.
3. Remove the drive flange, which is mounted
against the PTO flange.
4. Remove the attachment bolts from the
PTO side cover and remove the side cover
with the gasket.
5. Remove the drive shaft from the gearbox
and hang the drive shaft on the side of the
chassis.
6. Hold the drive flange in place with the
special tool (DAF No. 0484977).
7. Remove the attachment bolts from the drive
flange.
8. Remove the bolts and the locking plate from
the prop shaft flange.
9. Note:
Measure and make a note of the distance
from the drive flange to the shaft. The same
distance must be observed when the drive
flange is reinstalled.
Remove the prop shaft flange and O-ring
using a commercially available puller.
10. Remove the attachment bolts from the
bearing cover of the PTO and the two
attachment bolts located on the inside of the
PTO. Remove the entire PTO.
11. Remove the gasket, both O-rings and, in
the case of a gearbox with intarder, the
centring ring too.
13
ᓻ 200337
