3
PTO
Removal and installation CF65/75/85 series
4-14
4.12 REMOVAL AND INSTALLATION, PTO INTERMEDIATE SHAFT ON
GEARBOX WITH INTARDER
Removing intermediate shaft with intarder
1. Drain as much gearbox oil as necessary
and collect it in a clean container.
2. Remove the PTO.
3. Remove the intermediate housing from the
rear cover of the gearbox.
4. Remove the O-ring and the gasket.
5. Remove the intermediate shaft with bearing
and circlip from the rear cover of the
gearbox.
6. Remove the circlip and the intermediate
shaft bearing.
Installing intermediate shaft with intarder
1. Note:
The intermediate shaft can be installed
without any measurements being taken.
Install the bearing and the circlip on the
intermediate shaft.
2. Install the intermediate shaft in the rear
cover of the gearbox.
3. Install the intermediate housing with O-ring
and gasket onto the rear cover of the
gearbox.
4. Install the PTO.
5. Check the oil level in the gearbox.
13
ᓻ 200337
