3
PTO
Disassembly and assembly CF65/75/85 series
5-8
15. Fit the short drive shaft in the drive housing
so that the circlip abuts the drive housing.
V300652
16. If necessary, fit the shaft seals (1) in the
cover.
17. If necessary, fit the cover with the gasket
and oil seal and tighten the attachment nuts
to the specified torque. See “Technical
data”.
V300653
1
18. Apply sealant to the studs and tighten the
attachment nuts to the specified torque. See
“Technical data”.
19. If necessary, fit the drive flange.
20. If necessary, fit the sealing ring and O-ring
and tighten the attachment bolt to the
specified torque. See “Technical data”.
V300654
13
ᓻ 200337
