3
CF65/75/85 series Disassembly and assembly
PTO
5-7
11. Fit a gasket and the cover on the
PTO housing next to the lock nut and
tighten the attachment bolts to the specified
torque. See “Technical data”.
12. Turn the PTO housing round. If necessary,
apply Loctite to the studs and tighten them
to the specified torque. See “Technical
data”.
13. Fit the gasket and the drive housing.
Make sure that the oil channel in the gasket
is exactly opposite the lubricating hole in the
PTO housing.
V300650
14. If necessary, fit the bearing onto the short
drive shaft. Now place the circlip in the
bearing.
V300651
13
ᓻ 200337
