3
AS TRONIC GEARBOX
Removal and installation CF65/75/85 series
4-8
7. Put the round bolt (9) in upright position; it
has to fall into the recess of the pad on the
selection cylinder.
8. Install the gearbox modulator (1) with a new
seal (3); see that the control rods fall into
the recesses in the selector shafts (7, 8 and
9). Tighten the bolts (2) to the specified
torque. See “Technical data”.
9. Fit the gearbox.
10. Connect the battery terminal.
11. The new gearbox modulator must always
be reprogrammed using DAVIE XD and the
correct vehicle data.
V300832
4
9
7
8
6
5
3
2
2
1
14
ᓻ 200337
