DAF CF75 Series - Page 496

3
AS TRONIC GEARBOX
Removal and installation CF65/75/85 series
4-10
4. Disconnect connector 4 from the selector
switch. Remove the cover (5) with the
selector switch.
V300685
4
5
5. Disconnect connector 6 and remove the
attachment bolts (7) from the gear lever
unit; lift the gear lever unit and remove the
bolts (8) from the bottom plate (9). Remove
the gear lever unit with the bottom plate (9).
V300686
6
9
8
7
8
7
7
7
14
ᓻ 200337
