CF65/75/85 series Removal and installation
AS TRONIC GEARBOX
4-11
Fitting operating unit assembly
1. Install the bottom plate (9) with the gear
lever unit and fit connector 6.
V300686
6
9
8
7
8
7
7
7
2. Connect connector 4 and fit the cover (5)
with the selector switch.
Note:
Take care that the locking mechanism that
is fitted to prevent the bottom plate from
rotating relative to the gear lever does not
break during installation.
V300685
4
5
14
ᓻ 200337
