3
MECHANICAL GEARBOX CONTROL
Removal and installation CF65/75/85 series
3-2
Installation, entire gear lever unit
1. Fit the entire gear lever unit including the
set of air pipes to the bottom of the shift unit
or on the manifold bracket and fit the
attachment nuts (3), tightening to the
specified tightening torque. See “Technical
data”.
Note:
When fitting the set of air pipes, make sure
that these are away from any moving parts.
2. Fit the air pipes that run from the switch to
the various valves.
3. Fit the gear lever control rod (2) to the gear
lever unit and fit the clamping bolt (1),
tightening to the specified tightening torque.
See “Technical data”.
4. Check that the pneumatic system is airtight.
5. Check that all switches, both mechanical
and pneumatic, function properly.
2
ᓻ 0111
