DAF CF85 Series - 2.2 NEUTRAL POSITION VALVE

3
GEARBOX - PNEUMATIC SECTION
Description of components CF65/75/85 series
2-4
2.2 NEUTRAL POSITION VALVE
Situation with separate air distribution block:
V300140
Pneumatic symbol
Connection
point
Function
1 Supply
21 Cut-in pressure,
range-change switch
22 Plugged
Position Function
N Gearbox selector shaft in
neutral
V Gearbox selector shaft
engaged
N
V
1
21
22
V300160
4
ᓻ 200337
