CF65/75/85 series Description of components
GEARBOX - PNEUMATIC SECTION
2-3
Sectional drawing of integrated air
distribution block:
V300868
1 3 4 6 85 7 9 102
1. Neutral position valve
2. Neutral position valve attachment pin
3. Air distribution block
4. Neutral switch
5. Neutral position valve attachment pin
6. Locking cylinder
7. Locking cylinder lever
8. Reversing switch
9. Reversing switch attachment pin
10. Selector housing
4
ᓻ 200337
