TECHNICAL DATA
ZF 6S-850 gearbox CF65/75/85 series
4-2
4.2 TIGHTENING TORQUES
The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.
Gearbox to engine
M8 attachment bolts - 10.9 30 Nm
M10 attachment bolts - 10.9 60 Nm
M12 attachment bolts - 10.9 110 Nm
Drive flange
Drive flange attachment bolt
- 120 mm flange diameter 140 Nm
- 150 mm flange diameter 140 Nm
Gearbox front cover
Attachment bolts 23 Nm
Selector shaft housing
Attachment bolts 23 Nm
Shifting arm lock nut 46 Nm
Air connection banjo bolt 23 Nm
Bleeder 10 Nm
Plugs
Drainplug 50Nm
Level check/filler plug 50 Nm
4.3 FILLING CAPACITIES
Gearbox type Filling capacities at oil change
(litres)
First filling, e.g. during repair
(litres)
ZF 6S-850 7.5 7.5
0
ᓻ 200337
