CF65/75/85 series Description of components
GEARBOX - PNEUMATIC SECTION
2-11
Operation of the range-change gear
Changing to the low or high speed range is done
with a switch (B) on the front of the gear lever:
turn the switch down to select the low range
and up to select the high range. Pre-selection is
permitted. Switching itself takes place when the
gear lever passes neutral.
Operation of the splitter switch
Engaging half gears, or splitting, is done with the
switch (A) on the side of the gear lever. Tip the
lower end of the switch for low split selection
and the upper end of the switch for high split
selection.
When the switch has been operated, the clutch
pedal must be fully depressed, after which the
gear change is made.
Pre-selection is permitted.
When the splitter is in low split position, the
splitter warning lamp “splitter low” on the
instrument panel will illuminate.
B
A
D000096
4
ᓻ 200337
