0
3
CF65/75/85 series ZF 8/9/16S-109 gearbox
TECHNICAL DATA
5-3
Plugs
Gearbox with integrated intarder
Drainplug(B) M24 60Nm
Drain plug (B) M38 120 Nm
Drain plug (C) 60 Nm
Level check/filler plug (A). 60 Nm
Oil filter attachment bolt (1) 23 Nm
M3017
B
B
A
V300372
1
2
M3052
1
ᓻ 200337
