TECHNICAL DATA
ZF 8/9/16S-109 gearbox CF65/75/85 series
5-2
5.2 TIGHTENING TORQUES
The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.
Gearbox to engine
M8 attachment bolts - 10.9 30 Nm
M10 attachment bolts - 10.9 60 Nm
M12 attachment bolts - 10.9 110 Nm
Drive flange
Retaining plate attachment bolts 60 Nm
Gearbox front cover
Attachment bolts 25 Nm
Bearing cover
Output shaft bearing cover 25 Nm
Control bearing cover 25 Nm
Air connection banjo bolt 38 Nm
Shift control high/low
Shifting fork high/low bolts 180 Nm
Gear engaging cylinder piston lock nut 180 Nm
Gear engaging cylinder attachment bolts 50 Nm
Air connection banjo bolt 38 Nm
Rear gearbox cover attachment bolts 50 Nm
Plugs
M24 drain plug 60 Nm
M38 drain plug 120 Nm
Level check/filler plug 60 Nm
0
ᓻ 200337
