3
CF65/75/85 series Inspection and adjustment
PTO
3-1
3. INSPECTION AND ADJUSTMENT
3.1 INSPECTION AND ADJUSTMENT, DAF ENGINE PTO PROP SHAFT AXIAL
PLAY
Inspection and adjustment, DAF engine PTO
prop shaft axial play
1. Press the two outer bearing races into the
PTO housing.
2. Fit the inner bearing (2) onto the
engine PTO driving tool (1) (special tool,
DAF No. 1329341).
V300633
1
2
3
4
5
6
7
3. Fit the driving tool with the flat sides firmly
securedinavice.
4. Slide the PTO housing properly over the
driving tool.
V300634
5. Fit the filler sleeve (3) and 2 shims (4)
properly onto the driving tool (1).
Take note of the reconditioned rim in the
filler sleeve (3).
Note:
Use the driving tool to determine the correct
assembly of the filler sleeve and shims.
V300635
143
13
ᓻ 200337
