TECHNICAL DATA
ZF intarder CF65/75/85 series
11-2
Drive flange attachment bolts
Attachment bolts (8.8) 60 Nm
Attachment bolts (10.9) 120 Nm
Shift control high/low
Shifting fork high/low bolts 180 Nm
Gear engaging cylinder piston lock nut 180 Nm
Gear engaging cylinder attachment bolts 50 Nm
Air connection banjo bolt 38 Nm
Attachment bolts
rear gearbox cover 50 Nm
Heat exchanger
Studs in heat exchanger 18 Nm
(1)
Attachment nuts 62 Nm
(1)
Oil connection flange attachment bolt 23 Nm
(1)
Heat exchanger attachment surfaces Loctite 574
Hydraulic control unit
M10 attachment bolts 50 Nm
Sensors and transmitters
Temperature transmitter 40 Nm
Air supply valve 23 Nm
Proportional valve 23 Nm
Intarder attachment to gearbox
M10 attachment bolts 50 Nm
Oil pump
Attachment bolts 23 Nm
Oil filter
Attachment bolt 23 Nm
(1) Secure with Loctite 574
0
ᓻ 200337
