CF65/75/85 series PTO
TECHNICAL DATA
12-1
12. PTO
12.1 GENERAL
For the CF65/75/85 vehicle series, DAF has two
sorts of PTO:
the DAF engine PTO and the
ZF/Eaton gearbox PTOs.
The DAF engine PTO can be recognised by the
position of the PTO, i.e. on top of the flywheel
housing. The ZF/Eaton PTOs can be recognised
by the position at the rear of the gearbox.
DAF ENGINE PTO
Axial play
Drive gears between crankshaft and PTO 0.15 - 0.30 mm
PTO housing prop shaft bearings 0.02 - 0.1 mm
ZF GEARBOX PTO
Bearing axial play
Axial play on gearbox output shaft, in case of
attachment of N 211/10 PTO on gearbox
without intarder
0 - 0.1 mm
Axial play in case of attachment of NL/1 PTO
on N211/10 PTO
0 - 0.2 mm
á“» 200337
