TECHNICAL DATA
PTO CF65/75/85 series
12-2
12.2 TIGHTENING TORQUES
The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.
DAF ENGINE PTO
Main shaft lock nut 500 Nm
(1)
Gear attachment bolt in flywheel housing 110 Nm
Sealing plate at rear of flywheel housing 30 Nm
Output shaft flange bolt 110 Nm
Gear shift lever 30 Nm
PTO operating cylinder cover 30 Nm
Operating cylinder housing expansion plug Loctite 510
Attachment bolts, shift control on gearbox 30 Nm
PTO gearbox stud 68 Nm
(1)
Attachment nut, drive housing stud 68 Nm
(1)
Attachment, PTO housing to flywheel housing Loctite 510
Attachment bolt, PTO housing to flywheel
housing
40 Nm
Oil pipe banjo bolts 50 Nm
ZF GEARBOX PTO
Attachment NH/1-/4 and NL/1 -/4
Install attachment studs with a liquid gasket 25 Nm
Nuts for fastening attachment to gearbox 86 Nm
Attachment NH/1-/4 and NL/1 -/4 on
AS Tronic gearbox
Install attachment studs with a liquid gasket 18 Nm
Nuts for fastening attachment to gearbox 65 Nm
0
ᓻ 200337
