CF65/75/85 series AS TRONIC gearbox
TECHNICAL DATA
13-1
13. AS TRONIC GEARBOX
13.1 GENERAL
Gearbox type
Each gearbox has a type-plate attached to it,
indicating the type of gearbox. This data is also
stated on the identity card of the relevant
vehicle.
ZF gearbox type-plate
1. Type of gearbox
2. Series no. (ZF)
3. Parts list (ZF)
4. Specification no.
5. Pulse generator ratio
6. Gearbox ratio
7. Engine speed using PTO
8. PTO speed
9. Gearbox oil capacity
10. Oil specification
1
3
4
6
8
10
V300739
1
2
5
7
9
Output shaft bearing axial play
Output shaft bearing axial play 0 - 0.1 mm
ᓻ 200337
