User’s Manual
153
Parameter
Description
Video Matrix
Select the checkbox to enable the function. When an alarm event occurs,
the video output port outputs the settings configured in
Main Menu >
DISPLAY > Tour Setting
.
Not all models support this function.
Buzzer Select the checkbox to activate a buzzer noise at the Device.
Log Select the checkbox to enable the Device to record a local alarm log.
Disarming
After enabling this function, you can connect a switch to the alarm input
port for disarming control.
Click Apply to complete the settings.
 Click Default to restore the default setting.
 Click Copy to, in the Copy to dialog box, select the additional channel(s) that you want
to copy the local alarm settings to, and then click Apply.
5.10.2.2 Configuring Alarms from Alarm Box
You can connect the alarm box to the RS-485 port of the Device. When the alarm is detected by the
alarm box, the alarm information will be uploaded to the Device, and then the Device outputs the
alarms in the way that you configure in this section.
Select Main Menu > ALARM > Alarm-in Port > Alarm Box.
Alarm box
