User’s Manual
7
Install casing Figure 3-2
Table 3-1 Description of installation components
No. Description
No. Description
1 Two metal plates
4 Casing of the Barrier
2 Four M12 × 120 anchor bolts 5 Concrete foundation or pavement
3
Two sets of M12 nuts, spring gaskets
and flat gaskets
Installing Barrier Arm 3.3
Take out barrier arm accessories, and then install the straight arm or the folding arm shown as
the following figures.
