Installing straight arm Figure 3-3
Table 3-2 Description
No. Description
No. Description
1 Four M8 × 16 countersunk bolts 3 Lever
2
Two sets of M8 × 120 bolts, flat
gaskets and nuts
4 Straight arm
Installing folding arm Figure 3-4
