address, otherwise it can refresh to the newly added device and memorize the <PoE port>---

<Channel>.

b) If it is your second time to insert the PoE, system can check the saved MAC address

according to <Channel>---<IPC mac> map to make sure current IPC has connected or not. If

system finds the previous information and the channel is idle, system can map it to the

previously used channel. Otherwise system goes to the next step.

c) Thirdly, according to the <PoE port>---<Channel> map, system can know the previous

mapping channel of current PoE port. System can select current channel if it is free.

Otherwise, it goes to the next step:

d) Fourthly, system goes to find the first idle channel it can get.

Generally speaking, once you insert PoE, system follow the steps listed above to find the channel

available.

4) When you insert PoE, all channels are in use now.

System can pop up a dialogue box for you to select a channel to overwrite. The title of the pop-up interface

is the name of the current operation PoE port. In this interface, All PoE channel become grey and can not

select.

4.2 Login

Open IE and input NVR address in the address column. For example, if your NVR IP is 10.10.3.16, then

please input http:// 10.10.3.16 in IE address column.

System pops up warning information to ask you whether install webrec.cab control or not. Please click yes

button.

If you can’t download the ActiveX file, please modify your IE security setup.

After installation, the interface is shown as below. See Figure 4-1.

Please input your user name and password.

Default factory name is admin and password is admin.

Note: For security reasons, please modify your password after you first login.

Figure 4-1

4.3 Main Window
