Local Basic Operations 235
4.11 File Backup
You can back up the record file to the UBS device.
Step 1 Connect USB burner, USB device or portable HDD to the device.
Step 2 Select Main menu > BACKUP, the Backup interface is displayed. See Figure 4-207.
Figure 4-207
Step 3 Select backup device and then set channel, file start time and end time.
Step 4 Click Search button, system begins search. All matched files are listed below. System
automatically calculates the capacity needed and remained.
Step 5 System only backup files with a √ before channel name. You can use Fn or cancel
button to delete √ after file serial number.
Step 6 Click backup button, you can backup selected files. There is a process bar for you
reference.
Step 7 When the system completes backup, you can see a dialogue box prompting successful
backup.
Step 8 Click Backup button, system begins burning. At the same time, the Backup button
becomes Stop button. You can view the remaining time and process bar at the left
bottom.
