Dahua XVR4104C-S2 User Manual

419
Figure 4- 148
Step 5 Click OK button in Figure 4- 147.
Device goes back to Figure 4- 145.
Step 6 Check the Enable box to enable tripwire function. Click Apply or Save to
complete setup.
Device begins tripwire detection.
4.9.3.4 Intrusion (Cross warning zone) (Optional)
System generates an alarm once there is any object entering or exiting the zone in the
specified direction.

System supports customized area shape and amount.

Support appear/cross detection.

Can detect the moving object operation in the specified zone, customized trigger
amount and staying time.

Support objects filter function.
Step 1 From main menu->Setting->Event->IVS, click Add button and then select type as
intrusion, the interface is shown as below. See Figure 4- 149.

Dahua XVR4104C-S2 Specifications

General

Brand	Dahua
Model	XVR4104C-S2
Category	DVR
Language	English
