Dahua XVR4104C-S2 User Manual

421
2. Select direction, and then input customized rule name.

Name: Input customized rule name.

Action: You can set intrusion action: appear/cross.

Direction (Entry/Exit/Both): System can generate an alarm once there is
any object crossing in the specified direction.
 Target filter: Click , you can set filter object size. Each rule can set
two sizes (min size/max size). Once the object is smaller than the min
size or larger than the max size, there is no alarm. Please make sure
the max size is larger than the min size.
3. Left click mouse to draw a warning zone. Right click mouse to complete the
setup.
4. Click OK.
Complete drawing intrusion rule.
Step 3 Click , it is to set parameters.
Please refer to chapter 4.9.3.3 to set other parameters.
Step 4 Check the Enable box to enable intrusion function. Click Apply or Save to
complete setup.
Device begins intrusion detection.
4.9.3.5 Abandoned Object Detect (Optional)
System generates an alarm when there is abandoned object in the specified zone.

System supports customized area shape and amount.

Support duration setup.

Support objects filter function.
Step 1 From main menu->Setting->Event->IVS, click Add button and then select the
type as abandoned object. The object interface is shown as below. See Figure
4-151.
