Dahua XVR5216A User Manual

181
Network Video
Input
 There is no IP
channel by
default. Max
add 2 IP
channel
connections
 Analog
/digital channel
switch. Max 6
IP channel
connections
 Connection
bandwidth:0Mb
ps-24Mbps
 There is no IP
channel by
default. Max
add 4 IP
channel
connections
 Analog
/digital channel
switch. Max 12
IP channel
connections
 Connection
bandwidth:0Mb
ps-48Mbps
 There is no IP
channel by
default. Max
add 8 IP
channel
connections
 Analog
/digital channel
switch. Max 24
IP channel
connections
 Connection
bandwidth:0Mb
ps-96Mbps
Video Output
1-ch VGA output,
1-ch HDMI output,
HDMI/ VGA video output at the same time (VGA/HDMI of the same
video source)
Loop Output
N/A
Matrix Output
N/A
VGA/HDMI optional
Audio Port
External
Audio Input
1-ch,RCA port
Coaxial Audio
Input
4-channel
8-channel
16-channel
Audio Output
1-ch RCA port
Bidirectional
Talk Input
Support（Reuse the audio port of the 1
st
channel）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Playback
Channel
4-channel
8-channel
16-channel
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
1 RJ45 port,
1000Mbps Ethernet
port
RS485
Communication
RS485 port
