Dahua XVR5216A User Manual

182
USB
2 USB2.0 ports(One at the front panel and
one at the rear panel)
1 USB2.0 port and 1
USB3.0 port (One
USB2.0 port at the
front panel and one
USB3.0 port at the
rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
Model
Parameters
XVR5232AN-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
4M Lite/1080P@15fps/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps～6144Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM, AAC (AAC for the first channel only)
Audio
Sampling Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
32-ch BNC port (CVBS/CVI/AHD/other analog HD video
self-adaptive)
Network Video
Input
 There is no IP channel by default.
 Analog/digital channel switch. Max 32 IP channel connections.
 Connection bandwidth:0Mbps-128Mbps
