4 | About the box
Installer reference guide
21
2MXM-A, 3MXM-A, 4MXM-A, 5MXM-A
R32 Split series
4P600463-5E – 2021.12
CAUTION
ONLY handle the outdoor unit as follows:
NOTICE
▪ Place the unit on a flat surface.
▪ Make sure the aluminium fins on the unit are straight before installation. If not,
straighten them with a fin comb (field supply).
4.2.3 To remove the accessories from the outdoor unit
1 Lift the outdoor unit.
2 Remove the accessories from the unit (under service cover) and from the
bottom of the package.
1× 1× 2×
1×
6×
1×
a
1×
b c d e
3×
1×
1×
i j
g h
f
