10 English
For example.
When the timer is
programmed to stop
the system after
3 hours and start the
system after
4 hours, the system
will stop after
3 hours and then
1 hour later the sys-
tem will start.
NOTE
• After the timer is programmed, the display
shows the remaining time.
• When the system is installed as shown in
the following picture, it is necessary to des-
ignate the master remote controller.
■ For Heat pump system
When one outdoor unit is connected with
several indoor units.
HOW TO SET MASTER
REMOTE CONTROLLER
(For VRV system)
MODE
TIMER
RESERVE
CANCEL
DOWN
UP
FAN
TIME
TEMP
ON OFF
C
hr.
hr.
One of these remote controllers needs
to be designated as the master remote
controller.
Outdoor unit
Indoor units
■ For Heat recovery system
When one BS unit is connected with several
indoor units.
• Only the master remote controller can
select HEATING, COOLING or
AUTOMATIC (only Heat recovery system)
OPERATION.
When the indoor unit with master remote
controller is set to “COOL”, you can switch
over operation mode between “FAN”, “DRY”
and “COOL”.
When the indoor unit with master remote con-
troller is set to “HEAT”, you can switch over
operation mode between “FAN” and “HEAT”.
When the indoor unit with master remote
controller is set to “FAN”, you cannot switch
operation mode.
When attempting settings than those
consented above, a “beep” is emitted as a
warning.
Only with Heat recovery system, you can set
the indoor unit to AUTOMATIC. Attempting to
do so, a “beep” will be emitted as a warning.
How to designate the master remote
controller
Operate in the following order.
Continuously press the OPERATION
MODE SELECTOR button for 4 seconds.
One of these remote controllers needs
to be designated as the master remote
controller.
Outdoor unit
Indoor units
BS unit
MODE
