Daikin DM96VE - Page 71

71
SERVICING
Model
Primary Limit
Setting
Primary Limit
Part No.
Aux Limit
Setting
Aux Limit
Part No.
R.O.S Limit
Setting
R.O.S. Limit
Part No.
DM96VE0303ANAA 150 ±5 20162904 120 0130F00038 200 ± 8 10123539
DM96VE0403ANAA 150 ±5 20162904 120 0130F00038 240 ± 10 10123539
DM96VE0603ANAA 150 ±5 20162904 120 0130F00038 240 ± 10 10123539
DM96VE0302BN** 150 ±5 20162904 120 0130F00038 200 ± 8 10123533
DM96VE0403BN** 150 ±5 20162904 120 0130F00038 240 ±10 10123539
DM96VE0603CN** 150 ±5 20162904 120 0130F00038 240 ±10 10123539
DM96VE0803BN** 150 ±5 20162904 120 0130F00038 250 ± 9 0130F00123
DM96VE1004CN** 170 ±5 20162906 120 0130F00038 220 ± 7 10123534
DM96VE1205DN** 180 ±5 0130F00036 120 0130F00038 260 ± 6 10123527
DM96VE0804CN** 150 ±5 20162904 120 0130F00038 240 ±10 10123539
DM96VE1005CN** 160 ±5 20162903 120 0130F00038 220 ± 7 10123534
DM96VE* LIMIT INFORMATION
Set Point on Max Make Pressure Low Fire Low Fire High Fire High Fire Low / High
Pressure Fall Pressure On Switch Set Point on Max Make Set Point on Max Make Pressure Switch
(PF) W.C. Rise W.C. Part # Pressure Fall Pressure On Pressure Fall Pressure On Assembly
(PF) W.C. Ris e W.C. (PF) W.C. Rise W.C. Part #
DM96VE0303ANAA - 0.08 ± .04 - 0.16 0130F00647 - 0.15 ± .05 - 0.30 - 0.40 ± .05 - 0.55 0130F00643
DM96VE0403ANAA - 0.08 ± .04 - 0.16 0130F00647 - 0.10 ± .05 - 0.25 - 0.20 ± .05 - 0.35 0130F00644
DM96VE0603ANAA - 0.10 ± .05 - 0.25 0130F00646 - 0.10 ± .05 - 0.25 - 0.25 ± .05 - 0.40 0130F00645
DM96VE0302BNAB - 0.08 ± .04 - 0.16 0130F00486 - 0.67 ± .05 - 0.82 - 1.15 ± .07 - 1.36 0130F00472
DM96VE0402BNA* - 0.08 ± .04 - 0.16 0130F00485 - 0.72 ± .05 - 0.87 - 0.97 ± .05 - 1.12 0130F00471
DM96VE0603BN** - 0.10 ± .05 - 0.25 0130F00481 - 0.92 ± .05 - 1.07 - 1.47 ± .07 - 1.68 0130F00473
DM96VE0803BNA* - 0.10 ± .05 - 0.25 0130F00481 - 0.72 ± .05 - 0.87 - 1.47 ± .07 - 1.68 0130F00474
DM96VE0804CNAB - 0.10 ± .05 - 0.25 0130F00481 - 0.78 ± .05 - 0.93 - 1.25 ± .07 - 1.46 0130F00475
DM96VE1004CNA* - 0.10 ± .05 - 0.25 0130F00481 - 0.67 ± .05 - 0.82 - 1.15 ± .07 - 1.36 0130F00472
DM96VE1005CNAB - 0.10 ± .05 - 0.25 0130F00481 - 0.67 ± .05 - 0.82 - 1.25 ± .07 - 1.46 0130F00444
DM96VE1205DNA* - 0.10 ± .05 - 0.25 0130F00481 - 0.50 ± .05 - 0.67 - 1.15 ± .07 - 1.36 0130F00446
DC96VE0403BNAA - 0.10 ± .05 - 0.25 0130F00429 - 0.92 ± .05 -1.07 - 1.47 ± .07 - 1.68 0130F00435
DC96VE0603BNAA - 0.10 ± .05 - 0.25 0130F00429 - 0.92 ± .05 -1.07 - 1.47 ± .07 - 1.68 0130F00435
DC96VE0803BNAA - 0.10 ± .05 - 0.25 0130F00429 - 0.70 ± .05 - 0.87 - 1.47 ± .07 - 1.68 0130F00436
DC96VE1005CNAA - 0.10 ± .05 - 0.25 0130F00429 - 067 ± .05 - 0.82 - 1.15 ± .07 - 1.36 0130F00434
ID Blower
DM96VE Pressure Switch Trip Points And Usage Chart
Coil Cover
Model
