PRODUCT IDENTIFICATION
1
Natural Gas BTU/h
2
DOE AFUE based upon Isolated Combustion System (ICS)
3
Installer must supply one or two PVC pipes: one for combustion
air (optional) and one for the flue outlet (required).
Vent pipe must be either 2" or 3" in diameter, depending upon
furnace input, number of elbows, length of run and installation (1
or 2 pipes). The optional Combustion Air Pipe is dependent on
installation/code requirements and must be 2" or 3" diameter PVC.
4
Minimum Circuit Ampacity = (1.25 x Circulator Blower Amps) + ID
Blower amps. Wire size should be determined in accordance with
National Electric Codes. Extensive wire runs will require larger
wire sizes.
5
Maximum Overcurrent Protection Device refers to maximum
recommended fuse or circuit breaker size. May use fuses or
HACR-type circuit breakers of the same size as noted.
Notes
• All furnaces are manufactured for use on 115 VAC, 60 Hz,
single-phase electrical supply.
• Gas Service Connection 1/2" FPT
• Important: Size fuses and wires properly and make electrical
connections in accordance with the National Electrical Code and/
or all existing local codes.
• For bottom return: Failure to unfold flanges may reduce airflow
by up to 18%. This could result in performance and noise is-
sues.
• For servicing or cleaning, a 24" front clearance is required. Unit
connections (electrical, flue and drain) may necessitate greater
clearances than minimum clearances listed above. In all cases,
accessibility clearance must take precedence over clearances
from the enclosure where accessibility clearances are greater.
DM96VE
0403BNAA
DM96VE
0603ANA
DM96VE
0803ANA
DM96VE
1005CNAA
Heating Data
Hi gh Fi re Input¹ 40,000 60,000 80,000 100,000
Hi gh Fire Output¹ 38,400 57,600 76,800 96,000
Low-Fi re Stea dy-State Input¹ 28,000 42,000 56,000 70,000
Low-Fi re Stea dy-Sta te Output¹ 26,880 40,320 53,760 67,200
AFUE² 96969696
Temperature Rise Ra nge (°F) 25 - 55 25 - 55 40 - 70 36 - 65
Vent Di a me ter³ 2" - 3" 2" - 3" 2" - 3" 2" - 3"
No. of Burners 2345
Circulator Blower
Avai l a ble AC @ 0.5” ESP 1.5 - 3 1.5 - 3 1.5 - 3 3 - 5
Si ze (D x W) 10" x 8" 10" x 8" 11" x 8" 11" x 10"
Horsepower @ 1075 RPM 1/2 1/2 1/2 1 HP
Speed 5555
Electrical Data
Min. Circuit Ampacity
4
8888
Max. Overcurrent Device (AMPS)
5
15 15 15 15
DM96VE
0303ANA
DM96VE
0403ANA
DM96VE
0603ANA
DM96VE
0302BNA
DM96VE
0402BNA
DM96VE0
603BNB
DM96VE
0803BNA
DM96VE
0804CNA
DM96VE
1004CNA
DM96VE
1005CNA
DM96VE
1205DNA
Heating Data
High Fire Input¹ 30,000 40,000 60,000 30,000 40,000 60,000 80,000 80,000 100,000 100,000 120,000
Hi gh Fi re Output¹ 28,800 38,400 57,600 28,800 38,400 57,600 76,800 76,800 96,000 96,000 115,200
Low-Fire Stea dy-State I nput¹ 21,000 28,000 42,000 21,000 28,000 42,000 56,000 56,000 70,000 70,000 84,000
Low-Fire Stea dy-State Output¹ 20,160 26,880 40,320 20,160 26,880 40,320 53,760 53,760 67,200 67,200 80,640
AFUE² 9696969696969696969696
Temperature Ri se Ra nge (°F) 20 - 50 20 - 50 30 - 60 20 - 50 20 - 50 35 - 65 35 - 65 25 - 55 35 - 65 35 - 65 35 - 65
Vent Di ame ter³ 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3"
No. of Burners 22322344556
Circulator Blower
Available AC @ 0.5” ESP 1.5 - 31.5 - 31.5 - 31.5 - 21.5 - 31.5 - 31.5 - 32.5 - 41.5 - 4 3 - 5 3 - 5
Si ze (D x W) 11" x 6" 11" x 6" 11" x 6" 10" x 8" 10" x 8" 11" x 8" 11" x 8" 11" x 10" 11" x 10" 11" x 10" 11" x 11"
Hors epower @ 1075 RPM 1/2 1/2 1/2 1/2 1/2 1/2 1/2 3/4 1 1 1
Speed 55555555555
Electrical Data
Min. Circuit Ampacity
4
8.6 8.6 8.6 8 8 8 8 11.6 13.3 13.3 13.3
Max. Overcurrent Device (amps)
5
15 15 15 15 15 15 15 15 15 15 15
Shipping Weight (lbs)
106 107 110 111 112 115 118 123 140 140 154
