Daikin DWSC 050 - Page 4

D-EIMWC00804-14EN Centrifugal Chillers 5
Unit Control Panel
1
– Non flammable gas symbol
5
– Unit nameplate data
2
– Electrical hazard symbol
6
– Unit characteristics technical
3
– Gas type
7
– Emergency stop
4
– Control panel code
Compressor Control Panel
Motor Terminal Box
1
– Terminal box fixing
3
– Electrical hazard symbol
2
– Manufacturer’s logo
4
– Terminal connection
1 – Components layout 3 – Electrical hazard symbol
2 – Hazardous Voltage warning 4 – Compressor control panel code
