12 | Installer settings: Tables to be filled in by installer
User reference guide
63
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
4P620245-1A – 2021.02
12 Installer settings: Tables to be filled in by
installer
12.1 Configuration wizard
Setting Fill in…
System
Backup heater type [9.3.1]
Domestic hot water [9.2.1]
Emergency [9.5]
Number of zones [4.4]
Glycol Filled system (overview
field setting [E‑0D])
Booster heater capacity [9.4.1]
(if applicable)
Backup heater
Voltage [9.3.2]
Configuration [9.3.3]
Capacity step 1 [9.3.4]
Additional capacity step 2
[9.3.5] (if applicable)
Main zone
Emitter type [2.7]
Control [2.9]
Setpoint mode [2.4]
Schedule [2.1]
WD curve type [2.E]
Additional zone (only if [4.4]=1, dual zone)
Emitter type [3.7]
Control (read only) [3.9]
Setpoint mode [3.4]
Schedule [3.1]
WD curve type [3.C] (read only)
Tank (if applicable)
