4 | Quick guide
User reference guide
13
EWAA004~008D2 + EWYA004~008D2
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688016-1 – 2022.04
2 Adjust the desired room temperature.
+
–
21°C
1
a b
Room
a Actual room temperature
b Desired room temperature
To change the desired leaving water temperature
You can use the leaving water temperature setpoint screen to read out and adjust
the desired leaving water temperature.
1 Go to [2]: Main zone or [3]: Additional zone.
Main zone
2
Additional zone
3
2 Adjust the desired leaving water temperature.
+
–
20°C
2
ab
Main zone
+
–
12°C
3
ab
Additional zone
a Actual leaving water temperature
b Desired leaving water temperature
To change the weather-dependent curve for the space heating/cooling zones
1 Go to the applicable zone:
Zone Go to …
Main zone – Heating [2.5] Main zone > Heating WD
curve
Main zone – Cooling [2.6] Main zone > Cooling WD
curve
