Daikin FDM20JEVLK - Page 4

1-2
Outdoor Unit
N
L
KL
TN
M
A
D
O
PBQ
R
S
C
HG
F
E
IJ
All dimensions are in mm
Dimension
Model
ABCDEFGH I JKLMNOPQRS T
R(Y)D20JEVLK 855 628 328 508 181 44 93 149 101 113 603 126 164 15 49 3 23 73 75 362
R(Y)D25JEVLK 855 730 328 520 182 44 93 149 101 113 603 126 164 15 34 3 23 73 75 362
R(Y)D30JEVLK 855 730 328 513 182 44 93 149 101 113 603 126 164 15 47 3 23 73 75 362
Indoor Unit
All dimensions are in mm
Dimension
Model
ABCDEFGH I JKLMN
FD(Y)M50JEVLK 359 1369 1326 1287 594 384 541 256 173 306 256 161 248 220
FD(Y)M60JEVLK 359 1569 1526 1487 694 378 541 256 173 306 356 161 248 220
EE
AAK
B
C
K
D
MN
L
F
I
G
H
J
1 IM-CCC-0311(0)-DAIKIN (SASO).i2 2 6/9/11 10:07:35 AM
