5
■ Outdoor Unit
■
Indoor Unit
1. Air outlet
2. Air outlet grille: (Field supply)
•
Appearance of the Air outlet grille and Air inlet
grille may differ with some models.
3. Receiver
4. Suction grille: (Option)
•
Appearance of the suction grille and Air inlet
grille may differ with some models.
5. Air inlet
6. Room temperature sensor:
•
It senses the air temperature around the unit.
7. Operation lamp (green)
8. TIMER lamp (yellow): (page 16.)
9. HOME LEAVE lamp (red):
•
Lights up when you use HOME LEAVE
operation. (page 14.)
10. Indoor Unit ON/OFF switch:
•
Push this switch once to start operation.
Push once again to stop it.
•
This switch is useful when the remote controller
is missing.
•
The operation mode refers to the following table.
■
Outdoor Unit
11. Air inlet: (Back and side)
12. Refrigerant piping and inter-unit cable
13. Drain hose
14. Earth terminal:
• It is inside of this cover.
15. Air outlet
Appearance of the outdoor unit may differ from some models.
To Next Page
