30
Performance Data
Model: FCN25FV1 - RN25CV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
560
16°C
21°C 6.35 4.97 1.56 6.13 4.84 1.68 5.90 4.71 1.82 5.66 4.58 1.98 5.20 4.26 2.15 4.80 4.01 2.37
24°C 6.36 5.96 1.56 6.14 5.82 1.68 5.91 5.68 1.82 5.67 5.54 1.98 5.21 5.18 2.15 4.82 4.82 2.37
27°C 6.41 6.41 1.56 6.20 6.20 1.69 5.98 5.98 1.83 5.76 5.76 1.98 5.31 5.31 2.15 4.94 4.94 2.38
30°C 6.61 6.61 1.57 6.42 6.42 1.70 6.22 6.22 1.84 6.02 6.02 2.00 5.58 5.58 2.17 5.22 5.22 2.40
19°C
24°C 7.01 4.64 1.58 6.76 4.53 1.71 6.51 4.40 1.86 6.26 4.28 2.01 5.75 3.99 2.18 5.32 3.75 2.41
27°C 7.01 5.31 1.58 6.77 5.19 1.71 6.52 5.07 1.86 6.26 4.95 2.01 5.75 4.63 2.18 5.32 4.39 2.41
30°C 7.02 6.56 1.58 6.78 6.42 1.71 6.54 6.27 1.86 6.29 6.12 2.02 5.79 5.73 2.19 5.38 5.38 2.41
33°C 7.11 7.11 1.59 6.88 6.88 1.72 6.65 6.65 1.86 6.43 6.43 2.02 5.95 5.95 2.20 5.56 5.56 2.43
22°C
27°C 7.71 4.54 1.61 7.44 4.43 1.75 7.17 4.32 1.89 6.89 4.20 2.05 6.34 3.92 2.23 5.87 3.69 2.45
30°C 7.71 5.54 1.61 7.45 5.42 1.75 7.17 5.30 1.89 6.89 5.17 2.05 6.34 4.84 2.23 5.87 4.59 2.45
33°C 7.72 6.47 1.61 7.45 6.35 1.75 7.18 6.22 1.89 6.90 6.09 2.05 6.35 5.72 2.23 5.88 5.43 2.45
36°C 7.74 7.33 1.61 7.49 7.19 1.75 7.23 7.04 1.90 6.96 6.88 2.06 6.42 6.42 2.23 5.97 5.97 2.46
700
16°C
21°C 6.61 5.19 1.57 6.37 5.06 1.70 6.13 4.92 1.84 5.88 4.78 2.00 5.40 4.45 2.16 4.98 4.19 2.39
24°C 6.63 6.30 1.57 6.39 6.15 1.70 6.15 6.00 1.84 5.91 5.85 2.00 5.43 5.43 2.17 5.02 5.02 2.39
27°C 6.71 6.71 1.58 6.49 6.49 1.71 6.26 6.26 1.85 6.04 6.04 2.00 5.57 5.57 2.18 5.19 5.19 2.40
30°C 6.99 6.99 1.59 6.79 6.79 1.72 6.58 6.58 1.86 6.37 6.37 2.02 5.90 5.90 2.20 5.52 5.52 2.43
19°C
24°C 7.28 4.91 1.60 7.02 4.79 1.73 6.76 4.66 1.87 6.49 4.53 2.03 5.96 4.22 2.20 5.51 3.98 2.43
27°C 7.30 5.65 1.60 7.04 5.53 1.73 6.77 5.40 1.87 6.50 5.28 2.03 5.97 4.93 2.20 5.52 4.67 2.43
30°C 7.33 6.98 1.60 7.08 6.82 1.73 6.82 6.67 1.88 6.56 6.51 2.04 6.04 6.04 2.21 5.61 5.61 2.44
33°C 7.45 7.45 1.60 7.23 7.23 1.74 7.00 7.00 1.89 6.76 6.76 2.05 6.27 6.27 2.23 5.86 5.86 2.46
22°C
27°C 8.00 4.81 1.63 7.72 4.69 1.76 7.43 4.57 1.91 7.14 4.45 2.07 6.56 4.15 2.25 6.07 3.92 2.47
30°C 8.01 5.90 1.63 7.73 5.78 1.76 7.44 5.65 1.91 7.15 5.52 2.07 6.57 5.17 2.25 6.08 4.90 2.48
33°C 8.03 6.91 1.63 7.75 6.78 1.76 7.46 6.64 1.91 7.17 6.50 2.07 6.60 6.10 2.25 6.11 5.79 2.48
36°C 8.08 7.81 1.63 7.82 7.66 1.77 7.54 7.50 1.92 7.27 7.27 2.08 6.71 6.71 2.26 6.25 6.25 2.49
840
16°C
21°C 6.86 5.42 1.58 6.61 5.28 1.71 6.35 5.14 1.86 6.09 4.99 2.01 5.58 4.65 2.18 5.15 4.38 2.40
24°C 6.89 6.58 1.59 6.64 6.42 1.72 6.39 6.27 1.86 6.13 6.10 2.01 5.63 5.63 2.19 5.20 5.20 2.41
27°C 7.00 7.00 1.59 6.77 6.77 1.72 6.55 6.55 1.87 6.31 6.31 2.02 5.83 5.83 2.20 5.43 5.43 2.43
30°C 7.35 7.35 1.60 7.14 7.14 1.74 6.92 6.92 1.89 6.69 6.69 2.05 6.20 6.20 2.22 5.79 5.79 2.45
19°C
24°C 7.55 5.19 1.61 7.27 5.07 1.74 7.00 4.94 1.89 6.71 4.80 2.05 6.16 4.48 2.22 5.69 4.22 2.45
27°C 7.57 6.01 1.61 7.30 5.87 1.74 7.02 5.73 1.89 6.74 5.59 2.05 6.19 5.23 2.22 5.72 4.95 2.45
30°C 7.63 7.40 1.61 7.36 7.23 1.75 7.10 7.07 1.89 6.83 6.83 2.06 6.29 6.29 2.23 5.83 5.83 2.46
33°C 7.80 7.80 1.62 7.57 7.57 1.76 7.34 7.34 1.91 7.09 7.09 2.07 6.57 6.57 2.25 6.15 6.15 2.49
22°C
27°C 8.28 5.08 1.64 7.99 4.97 1.78 7.69 4.84 1.93 7.38 4.72 2.09 6.78 4.40 2.27 6.26 4.16 2.49
30°C 8.30 6.26 1.64 8.00 6.15 1.78 7.70 6.01 1.93 7.39 5.88 2.09 6.79 5.50 2.27 6.28 5.22 2.50
33°C 8.33 7.34 1.64 8.04 7.21 1.78 7.74 7.06 1.93 7.44 6.91 2.09 6.84 6.47 2.27 6.34 6.14 2.50
36°C 8.40 8.29 1.65 8.14 8.14 1.79 7.86 7.86 1.94 7.57 7.57 2.10 7.00 7.00 2.28 6.53 6.53 2.52
Remark:
AFR: Air ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB without pressure trip.
