Outline & Dimension
Model: RN35DV1 / RN40/50DY1
J
I
J
M NN
C
O
D
K
A
B
L
E
F
G H
Dimension
Model
A B C D E F G H I J K L M N O
RN35DV1
RN40DY1
RN50DY1
1030 826 400 695 57 72 90 40 746 142 60 26 448 22 28
Note: Dimension in mm
