Drain pumping out device (built-in)
Indoor unit
Drain pipe
Suction grille
Remote controller
Air outlet
Power supply wiring
Air ow ap (at air outlet)
Drain water removed from the room
during cooling.
Model name (Model name label)
(Inside suction grille)
Refrigerant pipe
Transmission wiring
Air lter (inside
suction grille)
Grounding wire
Conducts electricity from the unit into
the ground to prevent electric shock.
Thank you for purchasing this Daikin air
conditioner. Carefully read this operation manual
before using the air conditioner. It will tell you how
to use the unit properly and help you if any trouble
occurs. This manual explains about the indoor unit
only. Use it along with the operation manual for
the outdoor unit. After reading the manual, le it
away for future reference.
SAFETY CONSIDERATIONS
Read these SAFETY CONSIDERATIONS
carefully before installing air conditioning
equipment. After completing the installation, make
sure that the unit operates properly during the
startup operation. Instruct the customer on how to
operate and maintain the unit.
Inform customers that they should store this
Operation Manual with the Installation Manual for
future reference.
Meanings of DANGER, WARNING, CAUTION,
and NOTE Symbols:
DANGER ..... Indicates an imminently
hazardous situation which,
if not avoided, will result in
death or serious injury.
WARNING .... Indicates a potentially
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION ..... Indicates a potentially
hazardous situation which,
if not avoided, may result in
minor or moderate injury. It
may also be used to alert
against unsafe practices.
NOTE ........ Indicates situations that
may result in equipment or
property-damage accidents
only.
To Next Page
