Daikin FHQ35BVV1B Service Manual

Indoor Unit SiBE121135
68 Printed Circuit Board Connector Wiring Diagram
2.12 FDBQ25B8V1
Connectors and
Other Parts
[A1P]: Control PCB
1) X5A Connector for terminal board (for wired remote controller)
2) X10A, X11A Connector for transformer
3) X17A Connector for indoor heat exchanger thermistor
4) X18A Connector for liquid pipe thermistor
5) X19A Connector for room temperature thermistor
6) X21A Connector for fan motor
7) X27A Connector for terminal board (for inter-unit wiring)
8) X33A Connector for wiring adaptor PCB (option)
9) X35A Connector for group control adaptor (option)
10) X40A Connector for ON/OFF input from outside (option)
11) X60A, X61A Connector for interface adaptor (option)
12) HAP LED for service monitor (green)
13) SS1 Selector switch for emergency

Daikin FHQ35BVV1B Specifications

General

Model	FHQ35BVV1B
Category	Air Conditioner
Type	Ceiling Suspended
Cooling Capacity	3.5 kW
Heating Capacity	4.0 kW
Airflow Rate	10.5 m³/min
Refrigerant	R-32
Energy Efficiency Ratio (Heating)	3.61
Power Supply	220-240V, 50Hz
Outdoor Unit Noise Level	48 dBA
